Hugo KaTeX Module

March 22, 2023 1 min read Content Modules Docs KaTeX Math

On this page

Donate

Please check out the tutorial to start using Hugo modules.

KaTeX is the fastest math typesetting library for the web, this module integrates KaTeX with Hugo.

Module
`github.com/hugomods/katex`

Installation

1. Import Module

hugo.yaml

1module:
2  imports:
3  - path: github.com/hugomods/katex

hugo.toml

1[module]
2  [[module.imports]]
3    path = 'github.com/hugomods/katex'

hugo.json

1{
2   "module": {
3      "imports": [
4         {
5            "path": "github.com/hugomods/katex"
6         }
7      ]
8   }
9}

2. Import CSS

Please skip this step if your theme supports target="_blank" rel=“noopener noreferrer”>HugoPress, such as <a href=“https://hbstack.dev/"
target="_blank” rel=“noopener noreferrer”>HB Framework themes.

1{{ partial "katex/assets/css" . }}

3. Import JS

Please skip this step if your theme supports target="_blank" rel=“noopener noreferrer”>HugoPress, such as <a href=“https://hbstack.dev/"
target="_blank” rel=“noopener noreferrer”>HB Framework themes.

1{{ partial "katex/assets/js" . }}

Usage

Using KaTeX via Code Block

1```katex
2FORMULA HERE
3```

\tag*{(1)} P(E) = {n \choose k} p^k (1-p)^{n-k}

f(x) = \int_{-\infty}^\infty\hat f(\xi)\,e^{2 \pi i \xi x}\,d\xi

Using KaTeX via Shortcode

Parameter	Position	Type	Required	Default	Description
`formula`	`#0`	string	-	-	The formula, required when using inline shortcode.
`inline`	`#1`	boolean	-	`false`	Whether display inline.

Inline shortcode

1{{< katex [formula] [inline] />}}

Or use closing shortcode

1{{< katex >}}
2FORMULA HERE
3{{< /katex >}}

KaTeX Shortcode Examples

KaTeX Inline Shortcode Example

1Inline formulas: {{< katex formula="a^n" inline=true />}}, {{< katex "a^2+b^2=c^2" true />}}.

Inline formulas: $$a^n$$ , $$a^2+b^2=c^2$$ .

KaTeX Closing Shortcode Example

1{{< katex >}}
2\begin{array}{l}
3E*{o 1}=\frac{1}{2}\left( { target }*{o 1}- { out }_{o 1}\right)^{2}=\frac{1}{2}(0.01-0.75136507)^{2}=0.274811083 \\
4E_{o 2}=0.023560026 \\
5E*{ {total }}=E*{o 1}+E\_{o 2}=0.274811083+0.023560026=0.298371109
6\end{array}
7{{< /katex >}}

\begin{array}{l} E*{o 1}=\frac{1}{2}\left( { target }*{o 1}- { out }_{o 1}\right)^{2}=\frac{1}{2}(0.01-0.75136507)^{2}=0.274811083 \\ E_{o 2}=0.023560026 \\ E*{ {total }}=E*{o 1}+E\_{o 2}=0.274811083+0.023560026=0.298371109 \end{array}
